 Leupold VX-Freedom 3-9x40 Muzzleloader



Leupold® VX-Freedom™ Muzzleloader 3-9x40mm (1 inch) Matte Black Riflescope NZ$520 (incl. GST)
Reticle: Colour: Quantity:

Model # 174184 - Sabot Ballistics Reticle

A new generation of shooters deserves a new riflescope. With the VX®-Freedom™ you get best-in-class optics and unbeatable accuracy. It’s also everything you expect from a Leupold: designed, machined, and assembled in our Oregon factory, tested to the same ruggedness standards as our top-tier riflescopes, and guaranteed for a lifetime of performance.

The new VX-Freedom defines what a rifle scope should be: reliable, accurate, and extremely clear and bright. We’ve taken decades of American manufacturing combined with unbeatable optical performance and rolled it in to a scope that is guaranteed to get the job done every time.

With a host of new features, the VX-Freedom lets you unleash your rimfire, dominate from your tree stand, or stretch across an open draw with all the confidence in the world.



Specifications
* Model # 174184 - Sabot Ballistics Reticle
* Magnification: 3 - 9x
* Objective Lens Diameter: 40mm
* Finish/Colour: Matte Black
* Adjustment Click Value: 0.25 MOA
* Weight: 12.2 oz / 346 g
* Linear Field of View (ft/100 yd): 33.7 ft (Low) to 13.6 ft (High)
* Linear Field of View (m/100 m): 11.22 m (Low) to 4.54 m (High)
* Eye Relief (in): 4.17 in (Low) to 3.66 in (High)
* Eye Relief (mm): 106 mm (Low) to 93 mm (High)
* Elevation Adjustment Range (MOA): 60
* Elevation Adjustment Range (MIL): 17.5
* Windage Adjustment Range (MOA): 60
* Windage Adjustment Range (MIL): 17.5
* Length: 12.39 in / 31.5 cm
* Tube Length/Mounting Space: 5.38 in / 13.7 cm
* Eyepiece Length: 3.50 in
* Objective Length: 3.51 in
* Objective Diameter: 1.83 in
* Eyepiece Diameter: 1.56 in
* Tube Diameter: 1 in / 25.4 mm




Features of the Leupold® VX-Freedom™ Muzzleloader 3-9x40mm Riflescope

3:1 Zoom Ratio

A versatile 3:1 zoom ratio erector system that is ideal for virtually any situation.
  1/4 MOA Finger Click

1/4 MOA precision finger click adjustments for windage and elevation offer absolute repeatability and dependability over a lifetime of extreme use.

Waterproof & Fogproof

Absolute waterproof and fogproof integrity:  ready for a lifetime in the field, in all conditions.
  One inch Maintube

Durable and compact, the one-inch maintube is lightweight and fits more legacy rings.

6061-T6 Aircraft Quality Aluminum

Crafted from 6061-T6 aircraft quality aluminum.
  Scratch Resistant Lenses

Outer lens surfaces are scratch resistant to military standard extreme abrasion specification.

Twilight Light Management System

Reticles for the Leupold® VX-Freedom™ Muzzleloader 3-9x40mm Riflescope


Sabot Ballistics Reticle

Sabot Ballistics Reticle Features:
* Builds on the Leupold designed Duplex Reticle
* Tailored specifically to muzzleloaders and shotguns
* Utilizes a 100 yard zero
* Accurate aiming points out to 300 yards
* Marks on the power selector help users tune the reticle for their specific load
* Intended to be used on highest magnification in a rear or 2nd focal plane scope
* Non-caliber specific


More Pictures of the Leupold® VX-Freedom™ Muzzleloader 3-9x40mm Riflescope
